1.沼氣經濕法脫硫塔處理后，應布?xì)饩鶆?，出口處?yīng)設置硫化氫在線監測儀，準確顯示硫化氫濃度，脫硫后硫化氫含量控制在100ppm以下。
1. after the biogas is treated by the wet desulfurization tower, the gas distribution shall be uniform. An online hydrogen sulfide monitor shall be set at the outlet to accurately display the hydrogen sulfide concentration. The hydrogen sulfide content after desulfurization shall be controlled below 100ppm.
2.脫硫貧液經由脫硫塔頂部設置的噴淋布液裝置進入塔頂，沼氣由塔底進入塔體，沼氣與脫硫液在塔內及調料層間充分接觸，沼氣中的硫化氫被脫硫液完全吸收，吸收硫化氫后的脫硫富液進入富液槽，，脫硫后的沼氣脫硫后的沼氣由脫硫塔
2. the desulfurization lean liquid enters the tower top through the spray liquid distribution device set at the top of the desulfurization tower. The biogas enters the tower body from the tower bottom. The biogas and the desulfurization liquid are in full contact in the tower and between the seasoning layers. The hydrogen sulfide in the biogas is fully absorbed by the desulfurization liquid. The desulfurized rich liquid after absorbing the hydrogen sulfide enters the rich liquid tank. The desulfurized biogas is discharged from the desulfurization tower
3.富液槽：脫離富液流入富液槽，富液在槽內短時緩存熟化。富液槽內設置水封器，對沼氣與循環系統進行分離
3. rich liquid tank: the rich liquid is separated from the rich liquid and flows into the rich liquid tank. The rich liquid is stored and matured in the tank for a short time. A water seal is set in the rich liquid tank to separate the biogas from the circulating system
4.再生槽：反應槽，槽內設置噴射器，脫硫富液進行析硫反應，經過尾管流進浮選筒，在浮選筒進一步氧化再生。為溶液的再生和硫泡沫的分離做準備。
4. regeneration tank: the reaction tank is equipped with an ejector. The desulfurized rich liquid carries out sulfur separation reaction, flows into the flotation cylinder through the tail pipe, and is further oxidized and regenerated in the flotation cylinder. Prepare for regeneration of solution and separation of sulfur foam.
5.貧液槽：再生后的脫硫液流入貧液槽緩存，由脫硫泵打入脫硫塔內進行脫硫反應。
5. lean liquid tank: the regenerated desulfurization liquid flows into the lean liquid tank buffer and is pumped into the desulfurization tower by the desulfurization pump for desulfurization reaction.
6.泡沫槽：儲存硫泡沫，供后續硫處理系統使用。
6. foam tank: stores sulfur foam for subsequent sulfur treatment system.
